Light Carbon Construction
CAD – CNC Machine
Fully PVC Carbon Sandwich
Product Details
Click for more images.
| Volume | Length | Width | Height |
|---|---|---|---|
| 78 L | 4’9 / 146 | 23.5″ /59.8 | 4.6″ / 11.8 |
| 73 L | 4’8 / 142.9 | 23″ / 58.5 | 4’5″ / 11.5 |
| 68 L | 4’7 / 139.6 | 22.5″ / 57.1 | 4.4″ / 11.3 |
| 63 L | 4’5 / 136.1 | 21.9″ / 55.7 | 4.3″ / 11 |
| 58 L | 4’5 / 133 | 20.5″ / 52.1 | 4.3″ / 11 |
| 54 L | 4’3 / 131 | 19.9″ / 50.5 | 4.2″ / 10.7 |
| 50 L | 4’2 / 128.7 | 19.2″ / 49.6 | 4.1″ / 10.5 |
| 46 L | 4’1 / 125 | 19 / 48.2 | 4.0″ / 10.2 |
All sizes and weights, may change without any notice
CARVE MINI PRO V4
Since early 2023 we worked almost every single day on the re-design of this model. We made so many prototypes, got so much good feedback and were super motivated to improve the performance of this model until now, were it is ready for your order and added to our 2024 board range.
The Carve Mini Pro V4 is a mid-expert board for riders who weigh between 60 and 85 kilogram.
This model is more short compared to our Carve Mini ProV3 shape and has an improved rounded outline
The volume has been placed in the middle front of the board to have a better start while pumping, while the hull helps to improve the early glide and the little step helps to release the water easier.
The recessed deck allows you to use the board even without straps for free gliding experience.
Construction & Materials:
Fully carbon bottom and deck with EPS 15Kg/m3 and 3mm PVC 75 Kg/m3 HD bottom, 3mm PVC 75Kg/m3 on deck.
Features:
- Standard future track foil mount
- 3mm Eva PAD deck, diamond groove with 3M adhesive
- Opaque and anti UV Transparent clear coat finish, to maintain the original color even under the exposure for a long time in the sun
- Choose from 194 different color options
- The board design is fully customizable – choose from different existing design templates (new in 2024).
- Approximate weight: 3.7kg.(46 liters) up to 4,8 kg (78 liters)
Delivery time: 45 days
Board Bag not included
Shipping and custom fees not included
(technical specs may chance)
